Stock #: 70396
Status: In-Stock
Condition: Rebuilt
Make: Teco
Model: ASFA
Serial #: CY476071004
Output: 100 HP
RPM: 1800
Frame: 404T
Current: AC
Volts: 230/460
Amps: 234/117
Phase: 3
Cycles: 60
Pull: F1
Enclosure: ODP
Standard Dimensions



#70396


Click a thumbnail to enlarge


You may also want to look at the following similar motors
Stock # HP/KW RPM Frame AC/DC Make Volts VA VF Condition Encl.
64438 100 HP 1800 404T AC Lincoln 575 EOK ODP 3-Q1-C1
70336 100 HP 1800 404T AC Reliance 460 Rebuilt ODP 2-2305B1
70396 100 HP 1800 404T AC Teco 230/460 Rebuilt ODP 2-2211B2
70419 100 HP 1800 404T AC Lincoln 460 EOK ODP 5-02-B1
70420 100 HP 1800 404T AC Marathon 460 EOK ODP 5-12-A2
70904 100 HP 1800 404T AC Lincoln 230/460 EOK ODP 5-53-B1
71880 100 HP 1800 404T AC Weg 230/460 EOK ODP 9-FLOOR
